Self-designed products with multiple Invention and Design Patents, ensuring completely independent intellectual property rights.
★
Priority use of green environment-friendly technology and high-quality sustainable materials.
★
High-density integrated foamed seat and back cushions with ergonomic surface curvature for maximum comfort.
★
Main frame and key structures feature a minimum thickness of 3.0mm for superior stability.
★
Movement trajectory corresponds to biological principles of muscle movement for effective training.
★
Guide rods processed with centerless grinding and hard chrome plating for high precision and low noise.
★
Equipped with 7*19 plastic steel cable, with a maximum loading capacity of up to 1400kgs.
Material Specification & Technical Details
1. Main Frame: Q235 High Frequency Welded Pipe (118*75*3.0mm bread shape); Movement structure: Q235 120*50*3.0mm flat pipe; Force Arm: Q235 80*40*3.0mm flat elliptical pipe.
2. Ergonomic design with precise angles and trajectory; horizontal and vertical dual-position grips design to target more muscle groups.
3. Seat/back cushion utilizes an aluminum alloy force arm parallelogram structure with torsion spring assist for safe, fast combination adjustment.
4. Translucent ABS housing with surface texture treatment and aluminum alloy edging for a premium aesthetic and durability.
5. High resilience MC material for cushions with high-level PU leather covering; comfortable and long-lasting.
6. Weight stack selection is safely positioned on the right side; minimum increment of 5kgs with a total loading capacity over 70kgs.
7. High-tensile cables imported from Japan (6*19 + 1*75 spec) withstanding over 1400kgs of force.
Frequently Asked Questions
What materials are used for the main frame of the GF1001?
The main frame is constructed using Q235 high-frequency welded pipe with a thickness of 3.0mm, ensuring industrial-grade stability and durability.
Is the seating adjustable for different user heights?
Yes, the seat and back cushions use an aluminum alloy parallelogram structure with torsion spring assistance for quick and safe height adjustments.
What is the maximum weight capacity of the training cables?
The equipment uses 7*19 plastic steel cables imported from Japan, which can withstand a maximum tensile force of 1400kgs.
Can the colors of the frame and cushions be customized?
Yes, we offer customization options for both frame colors and cushion colors to match your gym or home decor requirements.
What are the primary target exercise areas for this machine?
The GF1001 model is specifically designed to target the back muscles, utilizing ergonomic trajectories for optimal muscle stimulation.
How is the noise level during operation?
Thanks to the centerless grinding process of the guide rods and the use of POM material pulleys, the movement is extremely smooth and operates with very low noise.
